hot dipped galvanized oval (elliptical) finned tubes, rectangular fin tubes

1. hot dipped galvanized oval (elliptical) finned tubes, rectangular fin tubes ( fin tubes ) is by setting up rectangular or square-shaped fins over Oval tube.

This fin tubes (pipes) maximizes the performance of Heat Exchangers and minimizes the loss of heat transfer and pressure.

fin pitch mm 2.3 2.5 2.8 3.2
fin quantit pc/m 416-455 390-410 345-370 302-322
heat transfer area (square meter/m) 1.15 1.05 0.95 0.85
weight (Kg/m)2.0/2.5 3.0/3.3 2.9/3.1 2.7/3.0 2.5/2.8
tube material carbon steel tubes (seamless or welded pipes)
Bare tube (mm) Long 36-0.2
Short 14-0.2
Fin material SPCC
Fin size (mm) 55*26*0.25
Zin layer (mm) 0.05-0.07
Turbulator quantity 4pcs,10 pcs or 26 pcs
length(m) 15000mm

oval fin tubes





2. galvanized oval (elliptical) finned tubes

Tube size: 100x20mm

Fin size: 120x49mm

Material: carbon steel tubes and carbon alloy steel tubes

oval fin tubes
